Converting the DotNetNukeŽ
Survey module to use the DAL+ (in VB and C#)
Also see:
The DAL vs. The DAL+
|
|
The DAL |
The DAL+ |
Using the normal DotNetNuke Data Access Layer (DAL) design, we would create a
database provider class (Concrete Provider) that communicated with the database and overrode methods
in an abstract class (Abstract Data Provider). The abstract class sits between the
concrete provider class and the Business Logic Layer (Controller Class). This would have allowed us to
substitute an alternate database provider class to communicate with other
databases.
The DAL+ does not require an Abstract Data Provider and it does not
require that you code a custom Concrete Provider. The DAL+ is a subset of
the DAL. It is comprised of 4 methods:
- ExecuteNonQuery - Used to execute a stored procedure that will
not return a value.
- ExecuteReader - Used to execute a stored procedure that will
return multiple records.
- ExecuteScalar - Used to execute a stored procedure that will
return a single value.
- ExecuteSQL - Used to execute a sql statement.
However, unlike the DAL, the DAL+ is not 100% portable to other data
sources. For example, if a module is developed using the DAL+ that retrieves
data using one stored procedure, an alternate database must be able to perform
the exact same functionality using only one stored procedure. In some cases this
is not possible due to differences in databases.
Converting the Survey Module to use the DAL+
As a demonstration of the DAL+, the Survey module (that uses the traditional
DAL) will be converted to use the DAL+ (you can download the original
C# Version of the Survey Module and the
VB Version of
the Survey Module).
To replace the DAL layer, we only need to alter the files that reside in the
App_Code directory.
Delete the highlighted files above so that only the following files remain:
Next, open the SurveyController.vb and SurveyOptionController.vb (or
SurveyController.cs and SurveyOptionController.cs if you're using
the C# version) and replace the GetSurveys, GetSurvey,
DeleteSurvey, AddSurvey, UpdateSurvey, GetSurveyOptions,
DeleteSurveyOption, AddSurveyOption, UpdateSurveyOption,
and AddSurveyResult methods with the
following code:
VB.NET
SurveyController.vb:
Public
Shared
Function GetSurveys(ByVal
ModuleId As
Integer)
As List(Of
SurveyInfo)
Dim
SurveyInfolist As
List(Of SurveyInfo)
= New List(Of
SurveyInfo)
Using dr
As IDataReader =
DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurveys",
ModuleId)
While dr.Read
Dim SurveyInfo
As SurveyInfo =
New SurveyInfo
SurveyInfo.SurveyId = Convert.ToInt32(dr("SurveyId"))
SurveyInfo.Question = Convert.ToString(dr("Question"))
SurveyInfo.OptionType = Convert.ToString(dr("OptionType"))
SurveyInfo.ViewOrder = Convert.ToInt32(ConvertNullInteger(dr("ViewOrder")))
SurveyInfo.CreatedByUser = Convert.ToInt32(dr("CreatedByUser"))
SurveyInfo.CreatedDate = Convert.ToDateTime(dr("CreatedDate"))
SurveyInfolist.Add(SurveyInfo)
End
While
End
Using
Return
SurveyInfolist
End
Function
Public
Shared
Function GetSurvey(ByVal
SurveyID As
Integer,
ByVal ModuleId
As
Integer)
As SurveyInfo
Dim SurveyInfo
As SurveyInfo =
New SurveyInfo
Using dr
As IDataReader =
DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurvey",
SurveyID, ModuleId)
While dr.Read
SurveyInfo.SurveyId = Convert.ToInt32(dr("SurveyId"))
SurveyInfo.ModuleId = Convert.ToInt32(dr("ModuleID"))
SurveyInfo.Question = Convert.ToString(dr("Question"))
SurveyInfo.OptionType = Convert.ToString(dr("OptionType"))
SurveyInfo.ViewOrder = Convert.ToInt32(ConvertNullInteger(dr("ViewOrder")))
SurveyInfo.Votes = Convert.ToInt32(ConvertNullInteger(dr("Votes")))
SurveyInfo.CreatedByUser = Convert.ToInt32(dr("CreatedByUser"))
SurveyInfo.CreatedDate = Convert.ToDateTime(dr("CreatedDate"))
End
While
End
Using
Return SurveyInfo
End
Function
Public
Shared
Sub DeleteSurvey(ByVal
objSurvey As
SurveyInfo)
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("DeleteSurvey",
objSurvey.SurveyId, objSurvey.ModuleId)
End
Sub
Public
Shared
Function AddSurvey(ByVal
objSurvey As
SurveyInfo) As
Integer
Return
CType(DotNetNuke.Data.DataProvider.Instance().ExecuteScalar("AddSurvey",
objSurvey.ModuleId, objSurvey.Question, GetNull(objSurvey.ViewOrder),
objSurvey.OptionType, objSurvey.CreatedByUser),
Integer)
End
Function
Public
Shared
Sub UpdateSurvey(ByVal
objSurvey As
SurveyInfo)
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("UpdateSurvey",
objSurvey.SurveyId, objSurvey.Question, GetNull(objSurvey.ViewOrder),
objSurvey.OptionType, objSurvey.CreatedByUser, objSurvey.ModuleId)
End
Sub
Public
Shared
Function GetNull(ByVal
Field As
Object)
As
Object
Return
Null.GetNull(Field, DBNull.Value)
End
Function
SurveyOptionController.vb:
Public
Shared
Function GetSurveyOptions(ByVal
SurveyId As
Integer)
As List(Of
SurveyOptionInfo)
Dim
SurveyOptionInfolist As
List(Of
SurveyOptionInfo) = New
List(Of
SurveyOptionInfo)
Using dr
As IDataReader =
DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurveyOptions",
SurveyId)
While dr.Read
Dim SurveyOptionInfo
As SurveyOptionInfo
= New
SurveyOptionInfo
SurveyOptionInfo.SurveyOptionId = Convert.ToInt32(dr("SurveyOptionID"))
SurveyOptionInfo.OptionName = Convert.ToString(dr("OptionName"))
SurveyOptionInfo.IsCorrect = Convert.ToString(dr("IsCorrect"))
SurveyOptionInfo.Votes = Convert.ToInt32(SurveyController.ConvertNullInteger(dr("Votes")))
SurveyOptionInfo.ViewOrder =
Convert.ToInt32(SurveyController.ConvertNullInteger(dr("ViewOrder")))
SurveyOptionInfolist.Add(SurveyOptionInfo)
End
While
End Using
Return SurveyOptionInfolist
End
Function
Public Shared
Sub
DeleteSurveyOption(ByVal
objSurveyOption As
SurveyOptionInfo)
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("DeleteSurveyOption",
objSurveyOption.SurveyOptionId)
End
Sub
Public Shared
Function
AddSurveyOption(ByVal
objSurveyOption As
SurveyOptionInfo) As
Integer
Return CType(DotNetNuke.Data.DataProvider.Instance().ExecuteScalar("AddSurveyOption",
objSurveyOption.SurveyId, objSurveyOption.OptionName,
SurveyController.GetNull(objSurveyOption.ViewOrder), objSurveyOption.IsCorrect),
Integer)
End
Function
Public Shared
Sub
UpdateSurveyOption(ByVal
objSurveyOption As
SurveyOptionInfo)
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("UpdateSurveyOption",
objSurveyOption.SurveyOptionId, objSurveyOption.OptionName,
SurveyController.GetNull(objSurveyOption.ViewOrder), objSurveyOption.IsCorrect)
End
Sub
Public Shared
Sub AddSurveyResult(ByVal
objSurveyOption As
SurveyOptionInfo, ByVal
UserID As
Integer)
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("AddSurveyResult",
objSurveyOption.SurveyOptionId, UserID)
End
Sub
C#
SurveyController.cs:
static
public
List<SurveyInfo>
GetSurveys(int
ModuleId)
{
List<SurveyInfo>
SurveyInfolist = new
List<SurveyInfo>();
using (IDataReader
dr = DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurveys",
ModuleId))
{
while (dr.Read())
{
SurveyInfo
colSurveyInfo = new
SurveyInfo();
colSurveyInfo.SurveyId = Convert.ToInt32(dr["SurveyId"]);
colSurveyInfo.Question = Convert.ToString(dr["Question"]);
colSurveyInfo.OptionType = Convert.ToString(dr["OptionType"]);
colSurveyInfo.ViewOrder = Convert.ToInt32(ConvertNullInteger(dr["ViewOrder"]));
colSurveyInfo.CreatedByUser = Convert.ToInt32(dr["CreatedByUser"]);
colSurveyInfo.CreatedDate = Convert.ToDateTime(dr["CreatedDate"]);
SurveyInfolist.Add(colSurveyInfo);
}
}
return
SurveyInfolist;
}
static
public
SurveyInfo GetSurvey(int
SurveyID, int
ModuleId)
{
SurveyInfo
colSurveyInfo = new
SurveyInfo();
using (IDataReader
dr = DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurvey",SurveyID,
ModuleId))
{
while (dr.Read())
{
colSurveyInfo.SurveyId = Convert.ToInt32(dr["SurveyId"]);
colSurveyInfo.ModuleId = Convert.ToInt32(dr["ModuleID"]);
colSurveyInfo.Question = Convert.ToString(dr["Question"]);
colSurveyInfo.OptionType = Convert.ToString(dr["OptionType"]);
colSurveyInfo.ViewOrder = Convert.ToInt32(ConvertNullInteger(dr["ViewOrder"]));
colSurveyInfo.Votes = Convert.ToInt32(ConvertNullInteger(dr["Votes"]));
colSurveyInfo.CreatedByUser = Convert.ToInt32(dr["CreatedByUser"]);
colSurveyInfo.CreatedDate = Convert.ToDateTime(dr["CreatedDate"]);
}
}
return
colSurveyInfo;
}
public
static
void DeleteSurvey(SurveyInfo
objSurvey)
{
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("DeleteSurvey",
objSurvey.SurveyId, objSurvey.ModuleId);
}
public
static
int AddSurvey(SurveyInfo
objSurvey)
{
return (Convert.ToInt32(DotNetNuke.Data.DataProvider.Instance().ExecuteScalar("AddSurvey",
objSurvey.ModuleId, objSurvey.Question, GetNull(objSurvey.ViewOrder),
objSurvey.OptionType, objSurvey.CreatedByUser)));
}
public
static
void UpdateSurvey(SurveyInfo
objSurvey)
{
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("UpdateSurvey",
objSurvey.SurveyId, objSurvey.Question, GetNull(objSurvey.ViewOrder),
objSurvey.OptionType, objSurvey.CreatedByUser, objSurvey.ModuleId);
}
public
static
object GetNull(object
Field)
{
return
DotNetNuke.Common.Utilities.Null.GetNull(Field,
DBNull.Value);
}
SurveyOptionController.cs:
public
class
SurveyOptionController
{
static
public
List<SurveyOptionInfo>
GetSurveyOptions(int
SurveyId)
{
List<SurveyOptionInfo>
SurveyOptionInfolist = new
List<SurveyOptionInfo>();
using (IDataReader
dr = DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurveyOptions",SurveyId))
{
while (dr.Read())
{
SurveyOptionInfo
colSurveyOptionInfo = new
SurveyOptionInfo();
colSurveyOptionInfo.SurveyOptionId =
Convert.ToInt32(dr["SurveyOptionID"]);
colSurveyOptionInfo.OptionName =
Convert.ToString(dr["OptionName"]);
colSurveyOptionInfo.IsCorrect = Convert.ToBoolean(dr["IsCorrect"]);
colSurveyOptionInfo.Votes = Convert.ToInt32(SurveyController.ConvertNullInteger(dr["Votes"]));
colSurveyOptionInfo.ViewOrder = Convert.ToInt32(SurveyController.ConvertNullInteger(dr["ViewOrder"]));
SurveyOptionInfolist.Add(colSurveyOptionInfo);
}
}
return
SurveyOptionInfolist;
}
public
static
void DeleteSurveyOption(SurveyOptionInfo
objSurveyOption)
{
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("DeleteSurveyOption",objSurveyOption.SurveyOptionId);
}
public
static
int AddSurveyOption(SurveyOptionInfo
objSurveyOption)
{
return (Convert.ToInt32(DotNetNuke.Data.DataProvider.Instance().ExecuteScalar("AddSurveyOption",
objSurveyOption.SurveyId, objSurveyOption.OptionName,
SurveyController.GetNull(objSurveyOption.ViewOrder),
objSurveyOption.IsCorrect)));
}
public
static
void UpdateSurveyOption(SurveyOptionInfo
objSurveyOption)
{
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("UpdateSurveyOption",
objSurveyOption.SurveyOptionId, objSurveyOption.OptionName,
SurveyController.GetNull(objSurveyOption.ViewOrder),
objSurveyOption.IsCorrect);
}
public
static
void AddSurveyResult(SurveyOptionInfo
objSurveyOption, int
UserID)
{
DotNetNuke.Data.DataProvider.Instance().ExecuteNonQuery("AddSurveyResult",
objSurveyOption.SurveyOptionId, UserID);
}
Essentially we are replacing code such as this:
DataProvider.Instance().GetSurveys(ModuleId)
with this:
DotNetNuke.Data.DataProvider.Instance().ExecuteReader("GetSurveys",
ModuleId)
In doing so we are able to eliminate the need to create an abstract provider
and a concrete provider. This saves hundreds of lines of code and potentially
hours of development.
In addition, the DAL+ allows you to connect to the database with a single
line of code. You do not have to set the database connection parameters
yourself.
You can download the complete DAL+
C# Version of the Survey Module and the
VB Version of
the Survey Module
